Vortex® CROSSFIRE® II 1-4X24

SKU: VORCF2-31037
Manufacturer part number: CF2-31037
GTIN: 875874005556
$289.99
V-Brite (MOA) Reticle | 30 mm Tube
+ -

OVERVIEW

A 30mm tube diameter, 4x zoom and incredibly versatile top-end magnification make this scope the perfect choice for an endless list of rifle-topping tasks. Exceptionally clear fully multi-coated optics and a superior build quality offered at a price point that will leave you scratching your head, in a good way! What’s not to like? Answer: nothing!

Build Your Own Custom Turret - Kenton Industries

Crossfire II 1-4x24 Dimensions (in inches)
Product Dimensions Image
Lengths
L1L2L3L4L5L6
9.612.781.906.17--3.44
Heights
H1H2
1.181.73

Included in the Box
  • Removable lens covers
  • Lens cloth
  • CR2032 battery
Magnification 1-4x
Objective Lens Diameter 24 mm
Eye Relief 4.0 inches
Field of View 96.1-24.1 ft/100 yds
Tube Size 30 mm
Turret Style Capped
Adjustment Graduation 1/2 MOA
Travel Per Rotation 30 MOA
Max Elevation Adjustment 100 MOA
Max Windage Adjustment 100 MOA
Parallax Setting 100 yards
Length 9.61 inches
Weight 14.8 oz
Product Manual (PDF) Download
Parts Diagram (PDF) Download

Fully Multi-Coated - Proprietary coatings increase light transmission with multiple anti-reflective coatings on all air-to-glass surfaces.

Second Focal Plane Reticle -
 Scale of reticle maintains the same ideally-sized appearance. Listed reticle subtensions used for estimating range, holdover and wind drift correction are accurate at the highest magnification.

Tube Size - 30 mm diameter provides maximized internal adjustment and strength.

Single-Piece Tube - Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproofness.

Aircraft-Grade Aluminum - Constructed from a solid block of aircraft-grade aluminum for strength and rigidity.

Waterproof - O-ring seals prevent moisture, dust and debris from penetrating for reliable performance in all environments.

Fogproof - Nitrogen gas purging prevents internal fogging over a wide range of temperatures.

Shockproof - Rugged construction withstands recoil and impact.

Hard Anodized Finish
- Highly durable hard-coat anodization provides a low-glare matte surface and helps camouflage the shooter's position.

Capped Reset Turrets
- Allow quick re-indexing of the turret (no tool needed) to zero after sighting in the riflescope. Caps provide external protection for turret.

Fast Focus Eyepiece - Allows quick and easy reticle focusing.

RETICLE

image of reticle

V-Brite (MOA)

Uses the V-Plex format along with battery-powered electronics to illuminate the center dot for better low-light performance. Good for hunters/shooters during extra-low light conditions.

Subtension detail for Crossfire II 1-4x24 riflescope with V-Brite MOA reticle.
